Servo cables excel in electromagnetic interference resistance, flexibility, wear resistance, and environmental adaptability, making them ideal for CNC machine tools, industrial robots, and automated production lines.
Anyon Industrial Cable's servo cables feature high-quality conductors and multi-layer insulation tailored for high-frequency movement and complex environments. Multi-strand finely twisted copper wires ensure superior conductivity and flexibility, while high-temperature, wear-resistant materials like PVC, PUR, or TPE provide reliable insulation and mechanical protection. A multi-layer shielding design minimizes electromagnetic interference, ensuring signal accuracy. The oil-, chemical-, and wear-resistant outer sheath guarantees durability in harsh conditions.
Motion-optimized stranding, wire diameter, pitch, and orientation are precisely combined to enhance the bending resistance of motion cables, ensuring superior performance in dynamic applications.
Common models: 4x0.5mm², 4x0.75mm², 4x1mm², 4x1.5mm², 4x2.5mm², 4*4mm²
Full shielding with an optimized braiding angle (70% line coverage, 90% optical coverage), precise pitch and twisting, and a high-pressure molded outer sheath ensures consistent structural stability.
Common models: 2x2x0.14mm², 3x2x0.14mm², 4x2x0.14mm² 5x2x0.14mm², 7x2x0.14mm², 8x2x0.14mm²
Common models: 2x2x0.2mm², 3x2x0.2mm², 4x2x0.2mm² 5x2x0.2mm², 7x2x0.2mm², 8x2x0.2mm²
Common models: 2x2x0.3mm², 3x2x0.3mm², 4x2x0.3mm² 5x2x0.3mm², 7x2x0.3mm², 8x2x0.3mm²
Optimal wire diameter, pitch, and direction improve motion cable bend resistance.
Opt for proper core wire components to safeguard the braided structure and maintain core wire positioning.
Fully shielded with an optimal braiding angle (70% line, 90% optical coverage).
Internal cable insulation must remain non-adhesive.
Built with a strong, high-tensile core and short pitch length.
The outer sheath, available in PVC, PUR, or TPE, can be tailored for UV, low-temperature, or oil resistance ect.
Using machines imported from Germany, 99.9% oxygen-free copper stranding is performed accurately to ensure the best performance of the cable.
The core wire is uniform in size and not eccentric, and is extruded into shape.
Surrounding the tight center, the cable structure is stable, ensuring the cable movement performance.
High-density tinned copper braided shielding combined with appropriate angles achieves the best balance between anti-interference performance and motion performance.
Our TUV-standard labs and testing centers feature advanced equipment, conducting tests like swing, bending, drag chain, aging, low-temperature, torsion, electrical, salt spray, combustion, and tension tests. Rigorous quality inspections ensure each product meets standards, delivering reliable quality assurance.
The company follows ISO 9001 management, with products certified by UL, CE, CCC, RoHS, TUV, and VDE, and holds more than 35 national cable patents.
Our warehouse and ample standing inventory enable faster order delivery, reduced production costs, and effective solutions for urgent customer needs.
